Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 230

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 230
Fig. 244. Direct-Connected Generator withOverhung Armature Fig. 245. Self-Oiling Bearing is for the pulley end, while that at the right is for the commutator end.Fig. 249 shows a form of mounting for vertical motors. It is differ-entiated from the horizontal type, simply by the introduction of…
