Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 345
l will be retained in the cavitybehind the rib, and not run out on the floor. Fig. 298 shows a piston, with studded junk plate designed for thisengine. The studs have a collar, which is let into a recess, and a small pindriven into the side to prevent it turning. The piston block is coned on a… … Fig. 381. TYPES OF STEAM-ENGINES—THE MILL ENGINE. 329 The remaining details for the same engine may be completed fromthe examples given in the previous chapter on Engine Details. Prosll Vaive Gear.—Fig. 382 represents a section of a cylinderfitted with the Proell valve gear, as made by Messrs.…
Steam-engines
