Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 318
Fig. 42. Horizontally Split Frame with Armature RemovedCourtesy of Furl Wayne Electric Works … Fig. 43. Fort Wayne Armature Tartly Wound 282 TYPES OF GENERATORS AND MOTORS 37 and c, Fig. 40. These are riveted together, slotted to about one-half their length, as shown at n, and provided with grooves m forholding them securely in the frame. After being cast welded intothe frame, they are…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
