Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 320
Fig. 44. One-Piece Frame of Type L F GeneratorCourtesy of Fort Wayne Electric Works these details, including the method of shifting the brush yoke. Thearmature is of the usual ironclad, one-piece coil, w^ell-ventilated type.A partly wound armature is shown in Fig. 43. Belt-Driven Types. Fort Wayne… … Fig. 45. Fort Wayne 3-Bcaring Belted Generator
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
