Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 384

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 384
Fig. 121. 5000 K. V. A., 6600 Volt, Three-Phase Water-Wheel Type Alternator Built forNorthern California Power Company … Fig. 122. Allis-Chalmers Type AN Belted Two-Bearing Alternator—Stator Moved Sidewajj 344 TYPES OF GENERATORS AND MOTORS 99 standard voltages for which these machines are designed are 2300,4400, 6G00, or 13200 for power station work and 240, 480, or 600 forlocal distribution in factories.…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
