Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 423
lig. 176. Stator of Bell Automatic Single-Phase Motor 382 TYPES OF GENERATORS AND MOTORS 137 from I to 15 h. p. for 110 or 220 volts, GO cycles. Their generalappearance is shown by Fig. 174. The line current passes into thefield or stator winding only, all currents in the armature being devel- … Fig. 176. Wound Armature of Bell Single-Phase Motor oped by induction. The stator, Fig. 175, consists of punchings of thehighest grade of laminated sheet iron, thoroughly annealed and slot-ted on the inner periphery to hold the field windings. These lam-inations are supported and protected by a…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
