Fig. 222. 13,200 Volt Synchronous Motor Connected to 1575 Volt DC GeneratorCourtesy of General Electric Company possible over a wide range, and the regulation is not so greatlyaffected by fluctuations in the supply circuit. Illustrations of thiskind of motor generator are given in Figs. 220, 221,… … Fig. 223. Low Voltage, 300 KW Direct-Current Motor-Generator SetCourtesy of Westinghouse Electric & Manufacturing Company 223 shows a low-voltage 300 k. w. direct-current motor-generatorset, manufactured by the Westinghouse Company. 420 TYPES OF GENERATORS AND MOTORS 175
