Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise .. (1916)
Swingle, Calvin F. (Calvin Franklin), b. 1846 · Chicago, F.J. Drake & company · leaf 623
dand the length of the low-pressure blades greatly reducedby subdividing this stage into two parts located at oppositeends of the rotor. As will be plain from what has preceded, the advantages 610 Steam Engineering sought in this form of turbine are constructional and me-chanical rather than… … Fig. 253 3,000 K. W. WESTINGHOUSE DOUBLE FLOW STEAM TURBINE ciple. The latter construction will also be used for thelow-pressure turbines to which it is so admirably adapted,as shown in Fig. 252, which is a section of the Westing-house low-pressure, double-flow, steam turbine designedfor utilizing…
