hown in detail in Fig. 61, the brush beingwide enough to span one commutator bar. In this case 10 amperes flow from either side of the armatureto the brush, the latter leading away 20 amperes. Suppose thebrush area to be one sq. in.; then, when the commutator is in theposition indicated by Fig. 61…
