and motor aremounted on a single cast-iron base, forming a very compact unit.Fig. 46 shows an electric hoist used in building construction. Anelectric drill is clearly illustrated in Fig. 47 connected by belt to therotary hammer shown in Fig. 48. The mechanism of the drill con- 104 MOTOR-DRIVEN… … Fig. 47. Electric Rock DrillCourtesy of Fort Wayne Electric Works r^\
