Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 378

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 378
pitman, J, to a crank and fly wheel, contains a longstraight tube at the top andtwo double inclined tubesbelow. A ball rolls along theupper tube by gravity in syn-chronism with the revolvingwheel and axle, so that its mo-mentum just carries it to thedrop valve and incline at F asthe crank reaches… … 933. PERPETUAL MOTION. Tilting tray and ball. Thisinvention consists in the arrangement of an annular tihing tray, whiclt^ forms the orbit for a revolving ball,in combination with a supportingplatform, and with a lever which ex-tends into the tray and connects witha shaft, to which motion is to be…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
