Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 158

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 158
Fig. 8. Diagram for Series Generator Showing Load, Field, and Armature, All in Series … Fig. 9. Diagram for Compound-Wound Generator series with the shunt field. As the load comes on, the voltage isautomatically regulated by the action of the series field. Thevoltage may be held practically constant from no load to full loador it may be increased at full load to 10 per cent or 15 per…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
