Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 159
e as the load decreases and decreaseits voltage as the load increases, the machine that has been relievedof its load would tend to raise its voltage and would immediatelytake more load. Shunt generators are, therefore, well adapted toparallel operation, but they are not often used because of… … Fig. 10. Wiring Diagram for Two Shunt-W^ound Generators in Parallel 140 MANAGEMENT OF DYNAMO-ELECTRIC MACHINERY 19 the shunt field; D, E, and F are single-pole single-throw switches;G, H, and / are buses; and R is the shunt-field rheostat. Theswitches D and F connect the main leads from the machine…
Electrical engineering
