Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 173
Fig. 120 162 PKACTICAL APPLIED ELECTKICITY … Fig. 121 these two points. Across a portion of this resistance, such asthat between the points (1) and (2), there is connected ashunt circuit which consists of a sensitive galvanometer(G), a standard cell (SC), a contact key (K), and a highresistance (H) that may be easily cut in or out of the…
Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
