Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 172
. 21. Wiring Diagram for 220-Volt<kneiator witli Balancor Set onThree-Wire System … Fig. 22. Wiring Diagram for Three-Wire System with Rotary Converter ShowingTransformer Connections Three-Wire Systems from Rotary Converters. Where rotaryconverters are used to supply a three-wire system, the neutralconductor can be connected either to the middle points of the 153 32 MANAGEMENT OF…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
