Twentieth century hand-book for steam engineers and electricians, with questions and answers .. (1905)

Swingle, C. F. [from old catalog], Horstmann, Henry Charles, 1858- [from old catalog], Tousley, Victor Hugo, 1875- [from old catalog] · Chicago, F. J. Drake & co. · leaf 467

An illustration from Twentieth century hand-book for steam engineers and electricians, with questions and answers .., 1905, leaf 467
dby the dynamo increases, and this is the purpose ofthe compound winding. The compound winding car-ries the total current of the dynamo around the fields,but only a few times, just often enough so that theincrease in magnetism resulting from this current may 48 ELECTRICITY FOR ENGINEERS make up for… … FIGURE 21. current dynamos because the current flow continues inone direction out of the positive or + side of thedynamo, to the external circuit, and back again to thenegative or - side of the dynamo. The current as itis generated in the coils of the armature which ELECTRICITY FOR ENGINEERS 49…
