Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 396
ll be described laterin connection with the axle-generator systems, while in other casesspecial boosters are installed. Fig. 64 shows a wiring diagram of asystem used by the Baltimore and Ohio Railroad, which system hasa lamp regulator on each car. Fig. 65 shows the wiring of one typeof booster… … 1100 s-ji^ys ^-05^
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
