llow pedestal on the collector end of the machine. The arviature is of the iron-clad ring type built up of smalloverlapping sheet-steel punchings, annealed and japanned to reducethe loss caused by hysteresis and eddy currents. The armature winding is of the concentrated or uni-coil type.The coils… … 150 ALTERNATING-CURRENT MACHINERY Westinghouse Uni=Coi! Armature. Figs. 153 and 154 show aWestinghouse single-phase uni-coil armature very much like theone used in the alternator shown in Fig. 151. The coils of the West-
