Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 196
he frame ofthe machine near the bottom and connected directly to the line or toterminal blocks which are mounted on the frame. The formerarrangement is usually employed. Rotating Field. The construction of the rotating field is verysimilar to that of the stationary armature except that the… … Fig. 164. Armature Coil Support Construction—General ElectricAlternator joints, and are fastened to the supporting structure. Three individualstampings are shown separate in the figure. In assembling the stampings that form the built-up structureof field poles and yokes, the stampings break joints…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
