Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 411

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 411
ructible, full protection beingafforded by them to the end connections withoutin any way interfering with perfect ventilation. The brush holders are of the standard slidingshunt type and are supported by cast-iron brack-ets. On the smaller sizes the brackets are boltedto the armature frame (see… … Westinghouse Shoe and Slide Railfor Type E Generator

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
