Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 205
CHINERY being rated at 2,500 kilowatts 2,300 volts, 60 cycles, and 133 revolu-tions per minute. The two small vertical shaft generators, locatedbetween the first and second large units, are exciters, each drivenindependently by a small water wheel installed below the main floorlevel. This practice… … Fig. 177. Interior View of Connecticut River Power Companys Hydroelectric Plant Fig. 178 shows an armature structure for a 600-kilowatt Allis-Chalmers water-wheel type alternator, with a three-phase wind-ing in place. This winding is distributed in two slots per pole perphase. The coils that…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
