Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 338
Fig. 265. Sectional View of Fort Wayne Shell-Type Transformer … Fig. 266. Sample Coils for Fort WayneTransformer 299 286 ALTERNATING-CURRENT MACHINERY Figs. 2G5 to 268 give a general view and structural details ofa 15-kw. shell-type transformer manufactured by the Fort WayneElectric Works. The shape of the core stampings is shown in Fig.265, which is a section…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
