Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 436
is circuit receives current from the other phase of the two-phase system. The terminals of the B circuit are shown at 11, Fig.330, The conductors which constitute one circuit are so connectedthat the current flows in opposite directions in adjacent groups ofconductors as indicated by the arrows in… … Fig. 333. Instantaneous Effect of AlternatingCurrent for a Given Position of Rotor Fig. 334. Magnetic Effect of Alternating Cur-rent 8 of a Cycle Later than in Fig. 333 are marked with crosses and those carrying up-flowing currents withdots. The action of the currents in these bands of conductors…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
