ons intermediate between those of 1940 APPLIED ELECTRICITY. the original pair; these pairs may then each have its owncommutator and brushes, and as the maximum and zero ofvalues of the E. M. F.s of the new windings occur at differ-ent periods of time from those of the first pair, the E. M. F.smay… … Fig. 1149. set containing four active conductors, those of one setoccupying a position on the core 90° from those of the other.Both sets are supplied with their two-segment commutators,which for convenience are represented as being concentric,A A being connected to a and a\ and B B to b and…
