Figs. 396 and 397. Vector Diagrams Showing E.M.F.Relations in the Line and in the Compensator tween its terminals. This current is transmitted over a line of whichthe resistance is R (including r) and the reactance is X (including 468 ALTERNATING-CURRENT MACHINERY 451 x), and the voltage at the… … VR I W/VsA/V^ Fig. 398. Wiring Diagram for Voltmeter Compensator as■Used in Practice in High Voltage Circuits explained on page 58. The relation between Eo, E, IR, and XI \sshown in Fig. 396. T, Fig. 395, is a transformer which supplies tothe voltmeter V a voltage exactly in phase with Eo, and,…
