Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 93
(a) Old Form of Moving Element (b) Modern Moving Element Fig. 71. Westinghouse Electrostatic Voltmeter plates Bi and B2, and the outer plate of each to the terminals Ti andT2. For high voltage readings the instrument is connected as ashunt across one of the two (or more) condensers in series,…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
