and tubes. The lug by which it isclamped to the frame is slotted to permit radial adjustment of theholder. The armature terminal lugs are cast as part of the brush-holderso that the current may be conducted away from a point as nearthe commutator as possible. No unnecessary heat is produced bythis… … Fig. 40. Brush Holders 130 ELECTRIC RAILWAYS 35 housings have bored seats and are clamped between the two halvesof the field casting. The axle-bearing bushings are split. Theyare supported by hollow extensions from the main frame and firmlyclamped between these and cast-steel axle caps above. The…
