Engineering reminiscences contributed to "Power" and "American machinist" (1908)

Porter, Charles T. (Charles Talbot), 1826-1910 · New York, J. Wiley · leaf 299

An illustration from Engineering reminiscences contributed to "Power" and "American machinist", 1908, leaf 299 — haft is kept inexact line, and shows also the solid support of the shaft quite outto the hub of the crank. This view contains one error. The capis not made a binder. I relied on the strength of the thick con-tinuous web of the bed under the boxes in addition to the depthof the bed. But we once had…

Steam-engines · Governors (Steam-engine) · Mechanical engineering
