Fig. 194. Bracket I-ine Construction wires; although not absolutely necessary, they greatly improve theinsulation of the hne and should in general be used. In the simplercurve suspension shown in Fig. 193, the pull-over wires are attached … Fig. 195. One Type of Bracket for Trolley Line to another wire which spans the two poles. This is a cheaper eon-struction than the other but not as substantial. Bracket Construction. A cheap method of construction con-sists in supporting the trolley wire from brackets mounted on a 305 208 ELECTRIC…
