Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 187
ment of Switching Apparatus. The arrangement of theswitching apparatus in a railway station follows in general the samelines as in lighting and power central stations. The fact that out-going lines are usually at very high voltages modifies this to someextent. The high tension switches, current… … Fig. 41. Wiring Diagram for Railway Generator and Six-Phase Rotary Converter 166 SWITCHBOARDS 69 TRANSMISSION SYSTEM SWITCHBOARDS Voltage. In nearly all interurban railway systems, it is necessaryto transmit power to sub-stations at more or less high voltage. Inwaterpower systems, high voltage…
