attachments are made in two ways:In one, there are two coils acting on a common plunger. One isconnected across the source of current and one in series with theline. When current flows in the usual direction, the two coils opposeeach other, and the plunger does not move. If, however, the… … Fig. 62. 2000-Ampere Hand-Operated CircuitBreaker Courtesy of Westinghouse Electric and Manu-facturing Company Fig. 63. Solenoid-Operated Circuit BreakerCourtesy of General Electric Company armature, which carries a small contact arm, stands against a stop,but when the current reverses, the…
