BATTERIES higher, but otherwise, from a technical standpoint, the installation isthe same. Ignition Service. When storage batteries are used in connec-tion with gas engines, it is always possible to take the current forthe ignition system from the batteries. If we refer to Fig. 49, itwill be… … TO SFARK PLUQTO ENG/tiE FRAME ^^/GN/T/ON SWITCH--BATTERr BOX Fig. 60. Complete Wiring Diagram for Simple House-Lighting Installation Courtesy of Electric Storage Battery Company Figs. 57 and 58 connections to the igniter in isolated plants. It iscustomary to provide a reserve sparking battery so…
