ents of the face-mould,draw the line m from d, square to the inclined line of the tangentsc d; revolve the bottom inclined tangent c to cut line m in n, wherethe joint is shown fixed; and from this point draw the line c to vj. Theintersection of this line with the upper tangent d forms the… … Joint
