Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 104
Fig. 82. Single Tenon Joint withTwo Tenons Fig. 83. Double Tenon Joint withFour Tenons strong hold on them. Fig. 84 shows this arrangement both in ele-vation and in section. It is useful in making up large panels fromnarrow boards. In this method, only one of the pieces must be gluedto the strip,…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
