Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 303
top toswing outward, or to receive the hinges in case it is hinged at 243 232 CARPENTRY the bottom to swing inward. The latter arrangement is the mostcommon one. The piece G forms the inside finish of the transombar and may be treated in any way desired. Mullions. In Fig. 333 is shown a double-hung… … Fig. 333. Double-Hung Window in Two Parts with Mullion Between A and C are usually made 8 or 9 inches wide, so as to provide spacefor the weight boxes in the thickness of the mullion. Fig. 334 showsa section taken horizontally through the mullion A, with spacesfor the weights at DD and with a strip…
