Fig. 25. Keyhole Saw with Detachable Blades Planes. Timber comes from the mills rough from the saw, andbefore it can be used for any finished work it must be prepared toreceive paint or other kinds of finish. This preparation consists ina. smoothing or planing which can be carried to any extent,… … Fig. 26. Jack Plane sandpapering or even polishing. The instruments used for therougher part of this work are called planes, after which, if moresmoothing is required, come scrapers and sandpaper. There, are agreat many different kinds ofplanes, but the principle of allof them is the same.…
