Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 87
Fig. 50. Double Tenon Joint … Fig. 51. Halved Joint Fig. 52. Dovetail Halved Joint will be in all respects equivalent to a single unbroken piece, and willsatisfy all of the requirements of the unbroken piece. This is reallythe only measure of the efficiency of a splice. 64 CARPENTRY 55
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
