between the first andsecond floors. This building is structurally of reinforced concrete,except that the interior columns in the lower floors were constructedof angles and plates and fireproofed with concrete. The power plantfor the building is to be located at a level of about seven feet belowthe… … Fig. 145. Steel Body End Dump Car. 305 290 MASONRY AND REINFORCED CONCRETE plank. Two guides are placed on opposite sides; also one on thefront, Fig. 146. The front guide was made in lengths equal to theheight of different floors of the building. Fig. 146 shows the locationof all the machinery, all…
