53. Forms for Beams and Slabs. A very common style of form for beam and slab construction is shown in Fig. 157. The size of the different mem-bers of the forms depends upon the size of the beams, the thickness of the slabs, and the relative spacing of some of the members. If the beam is 10 by on •… … 318 MASONRY AND REINFORCED CONCRETE 301 apart, will support the slab. The sides and bottom of the beamsare enclosed by l;y-inch or 2-inch plank supported by 3 by 4-inchposts spaced 4 feet apart. In Fig. 158 are shown the forms for a reinforced-concrete slab,with I-beam construction. These forms are…
