Figs. 229, 230, 231. can be faced. The bracket and shelf angles on the plate are for abeam framed between columns. 15-if … -/f// beams o/v /7i/s/? or? fop- Fig. 232. The student should be able to follow this detail and understandall the points without further explanation. 254 STEEL CONSTRUCTION 245 Fig. 224 shows another type of cohimn made of a web plate andfoin- angles with channels across the flange angles, the…
