Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 427
be tangent at point 4 and point 5 as indicated. Letter G. The letter G should start at the right side of theparallelogram and be tangent to the top, left side, and bottom aswell as the right-hand side where it extends upward to a height ofone-half of its total height before the horizontal line,… … Fig. 33. Proportion and Slant of Capitals across the letter and should be at an elevation of two-thirds theheight. Letter F. The letter / is but a part of the letter E as indicated. Letters P and R. P and R are constructed on the same generalprinciple. The upper part of both letters should be at…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
