Jamison, Alpha Pierce. [from old catalog] · New York, J. Wiley & sons; · leaf 54
figures are essen-tials of drawings. A drawing poorly figured—dimensioned—islike a drawing poorly lettered—the appearance is marred; how*ever, figures and letters go hand in hand, and a drawing poorlylettered is usually poorly figured, and vice versa; a draughtsmanwith the ability to do good…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
