Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 454
377 … THE HOTEL LASALLE, CHICAGO Nearly All Stages of the Construction of a Building are Shown in This Illustration,Courtesy National Fireproofing Co. STRUCTURAL DRAFTING PART II DETAILING METHODS Detailing of Angles. The line upon which the rivets are spacedis the gauge Hne. The standard gauges given in…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
