visions on the diagonal lines. Thereresults 3.1 and 2.3 which means that 3.1 rivets are required for Siand 2.3 for S2, or a total of 5.4 or 6 rivets for both. It may be that the problem is as is showy in Fig. 5Gc. In thiscase the method of procedure is similar. Here, after drawing o-lto the same…
