Fig. 56. Methods of Determining Number of Rivets in Connection Platefrom the Diagonal Other problems may be solved in a similar manner. The rivetspacing in the sides and tops is so arranged as to be equal and tofill out the plate, allowing the required edge distance. The platesshould be kept…
