Fig. GS. Typical Detail for the End of aRoof Truss Fig. 69. Method of Riveting ClipAngles for Carrying Purlins be exercised in making the layouts for the lateral plates so thatsufficient clearances are allowed, both in regards to clearances betweenmembers and clearances in rivet driving. The…
