e, being figured for the one withthe greater stress. Since a splice plate is a species of filler, it shouldbe given a mark so that in case of other splices occurring the markand not all the dmiensions should be placed upon it. Stiffeners. All stiffeners except the second from the end shouldhave the… … Fig. 71 Method of Detailing a Moment Web Splice have sufficient to take up the shear at that point. This would, ifcarried out, require a different number of rivets in each stiffener.Common practice requires that the spacing in all stiffeners shouldbe the same and that this spacing should be the…
