smaller plate. The bevels are notstated on the diagonals since the dimensions are given directly. The end distances should be given or, if not, a note stating theirvalue should be on the sheet. The distance, intersection to inter-section and end hole to end hole, should always be given, likewisethe… … Fig. 77. Detailing of Cross Frames put on the drawing. Attention is called to the detailing of thediagonals in C. F. 1, the center line being half way between the gaugesand a rivet placed on it at the ends. Rivet clearances should receive close attention. The first rivetin the horizontal leg of the…
