uq: CD I- d >< … ^ ^ I MECHANICAL DRAWING. 27 points of intersection of the radii with the laige circle ODE andF, draw vertical lines and from the intersection of the radii withthe small circle C, D. E, and F, draw horizontal lines intersect-ing the vertical lines. The intersections of these lines are pointson the…
