Ylix. 12. Fiff. 13. line 1) A may be drawn, and hy sliding the triangle along the edgeof the T-square to the position F the line B C may be drawn byusing the same edge. Tiiese positions are shown dotted in Fig. 15.If the rectangle is to be placed in some other position on thedrawing lx)ard, as…
